Description
SPECIFICATIONS
Model | Pump Volume @ Pump Head | Pump Pressure at Pump Head | Machine Voltage | Total Machine Amperage | Machine Weight | Shipping Weight | Machine Dimensions |
---|---|---|---|---|---|---|---|
1710 | 2.75 GPM | 1000 PSI | 120VAC/ 60Hz/1Ph | 20 Amps | 154 Lbs | 200 Lbs | L 31” X W 21” X H 16” |
1720 | 3.9 GPM | 2000 PSI | 230VAC/ 60Hz/1Ph | 28 Amps | 229 Lbs | 275 Lbs | L 31” X W 21” X H 16” |
1722 | 3.9 GPM | 2000 PSI | 208VAC/ 60Hz/1Ph | 30 Amps | 229 Lbs | 250 Lbs | L 31” X W 21” X H 16” |
1723 | 3.9 GPM | 2000 PSI | 208VAC/ 60Hz/3Ph | 16 Amps | 229 Lbs | 250 Lbs | L 31” X W 21” X H 16” |
1724 | 3.9 GPM | 2000 PSI | 230VAC/ 60Hz/3Ph | 14.4 Amps | 229 Lbs | 250 Lbs | L 31” X W 21” X H 16” |
1725 | 3.9 GPM | 2000 PSI | 460VAC/ 60Hz/3Ph | 7.2 Amps | 229 Lbs | 250 Lbs | L 31” X W 21” X H 16” |
1743 | 4.76 GPM | 3000 PSI | 208VAC/ 60Hz/3Ph | 31.3 Amps | 257 Lbs | 302 Lbs | L 31” X W 21” X H 16” |
1744 | 4.76 GPM | 3000 PSI | 230VAC/ 60Hz/3Ph | 26.8 Amps | 257 Lbs | 300 Lbs | L 31” X W 21” X H 16” |
1745 | 4.76 GPM | 3000 PSI | 460VAC/ 60Hz/3Ph | 13.5 Amps | 257 Lbs | 315 Lbs | L 31” X W 21” X H 16” |
1753 | 5.93 GPM | 2500 PSI | 208VAC/ 60Hz/3Ph | 31.3 Amps | 257 Lbs | 320 Lbs | L 31” X W 21” X H 16” |
1754 | 5.93 GPM | 2500 PSI | 230VAC/ 60Hz/3Ph | 26.8 Amps | 257 Lbs | 310 Lbs | L 31” X W 21” X H 16” |
1755 | 5.93 GPM | 2500 PSI | 460VAC/ 60Hz/3Ph | 13.5 Amps | 257 Lbs | 310 Lbs | L 31” X W 21” X H 16” |
1726 | 3.9 GPM | 2000 PSI | 575VAC/ 60Hz/3Ph | 6.6 Amps | 231 Lbs | 275 Lbs | L 31” X W 21” X H 16” |
1746 | 4.76 GPM | 3000 PSI | 575VAC/ 60Hz/3Ph | 9.6 Amps | 238 Lbs | 290 Lbs | L 31” X W 21” X H 16” |
1756 | 5.6 GPM | 2500 PSI | 575VAC/ 60Hz/3Ph | 10.3 Amps | 259 Lbs | 310 Lbs | L 31” X W 21” X H 16” |
