FORMWORK CLEANING MACHINE – LIMPIA

Machines to clean panels and boards for formwork

  • Monofase + Triphase
  • Motor : 0,75KW
  • Electropump : 0,11KW
  • Hourlyoutput : 200 Mtq/h
  • Working sizes : h 80-500mm
  • Workable Trickness : 25-50mm
  • Dimensions : 1240 x 950 x h1160
  • Weight : 225 kg



View Brochure

Category:

Description

QUALITY AND SAFETY OF TRIAX FORMWORK CLEANING MACHINE:

TRIAX builds formwork panels cleaners since many years, they are designed according to principles that make them reliable, fast and easy to use things that are extremely important on construction sites.

Our wooden shuttering cleaning machines are absolutely 100% Made in Italy in fact, we produce in our factory the whole machine (machining with CNC machines, welding, painting, assembly, etc.) and the components we buy (electric motor, hydraulic unit, electrical parts) are all made from trusted Italian suppliers with whom we work since long time. All machines are carefully tested before shipment so all this makes us certain that we have very high and consistent quality standards which TRIAX considered a primary matter.



ELECTRIC FORMWORK CLEANER DESCRIPTION:

It is used to clean formwork panels and wooden shuttering boards used for reinforced concrete formworks in building and construction sites. Easy to operate, cleans formwork planks and soak them with disarming oil preparing them for next use. Through the use of our formwork cleaning machines you can postpone much the need to buy new panels and planks. All electric controls work with low voltage 24V according to current regulations.

PANEL CLEANERS PRODUCED VERSIONS:

All TRIAX plywood cleaners are designed and built according to the criteria necessary to meet safety requirements established by current Machinery Directive 2006/42/EEC.



OTHER



USE OF THE FORMWORK CLEANING MACHINE:

The TRIAX shuttering planks cleaning machine allow you to automatically scrape concrete, clean and wash with disarming oil the upper-lower edges and the two sides of the wooden panels when they are removed from the concrete casts. Therefore these products help to considerably lower the labor costs and significantly improves the use of materials. The formwork panel inserted vertically into the planks cleaning machine, it is pulled by four dragging rollers that will also break and crumble away the layer of concrete encrusted without damaging the wood panel.

Also the cleaning of the wooden board is carried out by 24 independent scrapers oscillating on rubber joints that guarantee the complete scraping of the cement or mortar crust from the upper and lower edges and from the panel faces. The wood panel in the back of the machine is then washed by pressure jets of disarming oil and finally two springy blades made of wear-resistant hardened steel remove the oil in excess and refine the cleaning. The shuttering panels, workable although not perfectly regular or deformed by use, are now well cleaned and ready to be used again.



FORMWORK CLEANER MODELS:

The formwork cleaning machine is produced in single-phase and three-phase version. Our technicians are always available for the customer to study possible modifications of the standard machines to meet any needs of the building sites.



FORMWORK PANEL CLEANER TECHNICAL CHARACTERISTICS:

Vertical insertion of panels and formwork boards

Electric gearmotor 0.75 Kw.

Electric pump 0.11 Kw.

Hourly production about 700 linear meters/hour.

Shuttering panels and boards workable heights from 80 to 500mm.

Shuttering panels and boards workable thickness from 25 to 50mm.

Disarming products tank capacity 40 liters.

Four dragging rollers, grooved to facilitate the advancement of the formwork planks.

Twenty-four oscillating independent scrapers to ensure the adherence also on surfaces with deformations of the wood.

Four regulation screws to adjust the scraping pressure to fit the cleaning requirements.

Folding inlet guide and removable exit guide to reduce overall dimensions to facilitate transport.

Two pneumatic wheels for easy machine handling.
