Description
SPECIFICATIONS
| Model | URW706C |
|---|---|
| Maximum Lifting Capacity | Max. 6.05t at 3m |
| Maximum Working Radius | Min. 0.51m, Max. 18.6m |
| Max Hook height (Approx) Above ground level | Max. 19.5m |
| Max Hook height (Approx) Below ground level | Max. 23m (with 4-part line) |
| Boom Length | Min. 4.8m to Max. 19.2m |
| Boom Sections | 6 |
| Boom Raising Angle | Min. 0 ̊～Max. 80 |
| Slewing Angle (Continuous) | 360 ̊ |
| Mass of carne | 7.990 Kg |
