TRUCK MOUNTED CRANES-URV800

Max. Lifting Capacity	Max. Out Reach	Max. Recommended Tucks
8.07 t at 2.5	9.20 to 15.60 m	GVW 15 t and more

Max. Lifting Capacity

Max. Out Reach

Max. Recommended Tucks

8.07 t at 2.5

9.20 to 15.60 m

GVW 15 t and more

Description

Model	URV803	URV804	URV805
Maximum Lifting Capacity	8,070kg at 2.5m	8,070kg at 2.5m	8,070kg at 2.5m
Maximum Hook Height	Max. 11.1m	Max. 14.4m	Max. 17.5m
Maximum Working Radius	Min. 0.65m to Max. 9.20m	Min. 0.67m to Max. 12.50m	Min. 4.40m to Max. 15.90m
Boom Length	Min. 4.20m to Max. 9.50m	Min. 4.30m to Max. 12.80m	Min. 3.78m to Max. 13.38m
Boom Sections	3	4	5
Boom Raising Angle	Min. 1 ̊ to Max. 80 ̊	Min. 1 ̊ to Max. 80 ̊	Min. 1 ̊ to Max. 80 ̊
Slewing Angle (Continuous)	360 ̊	360 ̊	360 ̊
